• Designs available in 5LPM, 10LPM and 15LPM.
• Made from SS Extrusions (Machined) and not from castings, hence reducing the chances of manufacturing defects like blow holes and shrinkage.
• Can be manufactured from SS 316/SS 304/SS 202 based on project technical specification.
• CNC machined for better dimensional accuracy resulting in precise output flow.
• Indigenous sturdy design - tested for PN16 rating for water pressure.
• Fully automatic working, hence no manual flow adjustment required. Output flow has a saturation limit; hence water loss due to installation of suction pumps is prevented.
• Single body design prevents unnecessary fiddling and reduces water losses as in case of conventional brass ferrule.
• In-built NRV (Non Return Valve) hence only unidirectional flow allowed.
• Zero maintenance.
• Factory calibrated design hence, once installed immediately ready to use. FCRI Tested for output flow calibration for given line pressure.

Features	Parts	Specification
MOC	Main Body / Ball	SS 316/SS 304/SS 202
Sizes	Outlet	1/2" (15 mm), 1/4" (20 mm) & 1" (25 mm)"
LPM		5, 10 & 15 LPM (Customization possible)
Variants	Inlet - Outlet	Male-Male, Male Female, Female - Female
